DS-8 Series_Zhongshan Minglian Electronic Co.,Ltd;

DS-8 Series

IP33 Rainproof Constant Voltage Switching Power Supply

Features:
1.Constant Voltage design
2.Universal AC input
3.Withstand 300VAC surge input for 5seconds
4.Protections:Short circuit/Over load/Over current
5.Cooling by free air convection
6.100% full load burn-in test
7.High Reliability

Model
Input Voltage
Power Factor
Maximum Output Voltage
Output Current
Output Power
Product Size(mm)

DC-8040-12 100 - 265VAC PF≥0.96 12V 3.3A 40W 130*73*42
DC-8040-24 100 - 265VAC PF≥0.96 24V 1.67A 40W 130*73*42
DC-8060-12 100 - 265VAC PF≥0.96 12V 5A 60W 130*73*42
DC-8060-24 100 - 265VAC PF≥0.96 24V 2.5A 60W 130*73*42
DC-8100-12 100 - 265VAC PF≥0.96 12V 8.3A 100W 142*73*42
DC-8100-24 100 - 265VAC PF≥0.96 24V 4.1A 100W 142*73*42
DC-8120-12 180 - 265VAC PF≥0.96 12V 10A 120W 142*73*42
DC-8120-24 180 - 265VAC PF≥0.96 24V 5A 120W 142*73*42
DC-8200-12 180 - 265VAC PF≥0.96 12V 16.5A 200W 137*120*60
DC-8200-24 180 - 265VAC PF≥0.96 24V 8.3A 200W 137*120*60
DC-8300-12 180 - 265VAC PF≥0.96 12V 25A 300W 182*120*60
DC-8300-24 180 - 265VAC PF≥0.96 24V 12.5A 300W 182*120*60
DC-8400-12 180 - 265VAC PF≥0.96 12V 33A 400W 173*115.5*56
DC-8400-24 180 - 265VAC PF≥0.96 24V 16.6A 400W 173*115.5*56
DC-8600-12 180 - 265VAC PF≥0.96 12V 50A 600W 216*120*60
DC-8600-24 180 - 265VAC PF≥0.96 24V 25A 600W 216*120*60
